Devola Panel Heater User Manual: A Comprehensive Guide
Welcome! This manual provides detailed instructions for operating your Devola panel heater, ensuring efficient and safe heating within your home environment.
Explore features like automatic and manual timer modes, frost protection, and child safety locks, all designed for user convenience and energy conservation.
Devola panel heaters represent a modern approach to home heating, combining sleek design with efficient functionality. These heaters are engineered to provide comfortable and consistent warmth, utilizing advanced technology for optimal performance and energy savings.
The Devola range includes various models – 1kW, 1.5kW, and 2.4kW – catering to different room sizes and heating needs. Each heater boasts user-friendly features, including programmable timers and multiple operating modes, allowing for personalized comfort and reduced energy consumption.
Designed for ease of use, Devola heaters are simple to install and operate, featuring intuitive control panels. Safety is paramount, with features like child safety locks and frost protection integrated into the design. Whether you’re looking for supplemental heat or a primary heating solution, Devola offers a reliable and stylish option for your home. This manual will guide you through the features and operation of your new Devola panel heater.
Understanding Your Devola Heater Model
Your Devola panel heater is designed for efficient and safe operation. Models are available in 1kW, 1.5kW, and 2.4kW power ratings, influencing heating capacity. The DVM2000W specifically features a 7-day timer for advanced scheduling. All models share core features like automatic and manual timer modes, frost protection, and a child safety lock.
The 1.5kW and 2.0kW Glass Panel Heaters are wall-mounted, offering a modern aesthetic. The Eco Contour range emphasizes eco-friendly operation with personalized heating schedules. Each heater has an IP24 rating, indicating protection against solid objects and splashing water, suitable for most rooms.
Familiarize yourself with the control panel, which governs power, temperature, and timer settings. Refer to the detailed control panel overview section for specific symbol explanations. Understanding your model’s capabilities ensures optimal performance and maximizes energy efficiency. Always consult the included documentation for model-specific details.
Safety Precautions
Important: Always read these safety precautions before operating your Devola panel heater. Ensure the heater is used on a stable, level surface, avoiding areas with flammable materials. Never cover the heater during operation, as this poses a fire risk. Do not use the heater in bathrooms or near water sources;
Keep the heater out of reach of children and pets, utilizing the child safety lock function when necessary. Avoid using extension cords; plug directly into a grounded outlet. Regularly inspect the power cord for damage, and discontinue use if any are found.
Do not attempt to disassemble or repair the heater yourself; contact qualified personnel for servicing. Unplug the heater before cleaning. Always read the manual before use and retain it for future reference. Failure to follow these precautions may result in injury or damage.
Package Contents
Upon opening your Devola panel heater package, please verify that all components are present and undamaged. The standard package includes the Devola panel heater unit itself, available in 1kW, 1.5kW, or 2.4kW models. You should also find a set of mounting brackets and screws for optional wall installation.
A comprehensive user manual, providing detailed operating instructions and safety guidelines, is included. Some models, such as the DVM2000W, may include specific accessories related to the 7-day timer functionality. Carefully inspect all items against the packing list provided within the box.
If any components are missing or appear damaged, please contact our customer support team immediately for assistance. Retain the original packaging for potential returns or warranty claims.
Getting Started
Begin by carefully reading all safety precautions before installation. Ensure proper placement, secure mounting, and connect to a grounded power outlet for optimal performance.
Initial Setup and Installation
Unpacking and Inspection: Carefully unpack your Devola panel heater and verify all components are present. Inspect the unit for any visible damage incurred during shipping. If damage is detected, do not operate the heater and contact customer support immediately.
Location Selection: Choose a suitable location for your heater, ensuring adequate space around the unit for proper ventilation. Avoid placing the heater near flammable materials, curtains, or furniture. The heater should be positioned on a stable, level surface or securely mounted to a wall (see mounting instructions).
Electrical Connection: Before plugging in the heater, confirm your electrical outlet matches the heater’s voltage requirements. Use a grounded outlet to prevent electrical shock. Do not use extension cords or adapters; Ensure the power switch is in the ‘off’ position before connecting the heater to the power source. A qualified electrician should perform any necessary electrical work.
Mounting the Heater (Wall Mounting Instructions)
Safety First: Before commencing installation, disconnect the heater from the power supply. Wall mounting should be performed by a competent person, ensuring adherence to local building regulations.
Bracket Installation: Identify the mounting bracket included with your heater. Using a level, mark the desired mounting location on the wall, ensuring sufficient space around the heater. Drill pilot holes at the marked locations. Securely attach the mounting bracket to the wall using appropriate screws and wall plugs (not always supplied, depending on wall type).
Heater Attachment: Carefully lift the heater and align the mounting slots on the back of the unit with the installed bracket. Gently lower the heater onto the bracket, ensuring it is securely seated. Double-check the heater’s stability before restoring power. Incorrect mounting may result in the heater falling and causing damage or injury.
Powering On and Basic Operation
Initial Power-Up: After installation, plug the heater into a grounded electrical outlet. The power indicator light should illuminate, signifying the unit is receiving power. Press the power button located on the control panel to activate the heater. A confirmation sound or display change may indicate successful activation.
Basic Heating: Once powered on, the heater will begin to warm up; Use the temperature adjustment controls (detailed in the next section) to set your desired room temperature. The heater will automatically cycle on and off to maintain the set temperature.
Initial Test: Allow the heater to run for a short period to verify proper operation. Monitor the temperature output and ensure the unit is functioning as expected. Refer to the troubleshooting section if any issues arise. Always read the manual before use.
Control Panel Overview
The intuitive control panel allows easy operation of your Devola heater, featuring clearly marked buttons for power, temperature, timer settings, and advanced functions.
Understand each symbol for optimal control!
Understanding the Control Panel Symbols
Decoding the symbols on your Devola panel heater’s control panel is crucial for effortless operation. The power button, often depicted as a circle with a vertical line, initiates or terminates heater function. Indicator lights signal whether the heater is on, actively heating, or in standby mode.
Temperature adjustment symbols, typically plus (+) and minus (-) signs, control the desired room temperature. A snowflake icon represents frost protection mode, preventing freezing temperatures. A clock or timer symbol accesses the timer functions, enabling scheduled heating.
The child safety lock symbol, usually a padlock, activates a key lock preventing accidental button presses. Eco mode is indicated by a leaf or similar symbol, optimizing energy consumption. Familiarizing yourself with these symbols ensures you can fully utilize your heater’s capabilities and customize your heating experience.
Power Button and Indicator Lights
The power button, prominently located on the control panel, is your primary control for activating and deactivating the Devola panel heater. A single press initiates the heater, while another press returns it to standby mode. Observe the indicator lights to understand the heater’s current status.
A solid, illuminated power indicator confirms the heater is on and operational. A flashing indicator might signal the heater is warming up or has detected an error. Some models feature separate indicators for heating level or mode selection (Eco, Frost Protection).
Pay attention to these visual cues; they provide immediate feedback on the heater’s functionality. If the indicator lights behave unexpectedly, consult the troubleshooting section of this manual for guidance. Proper understanding of these lights ensures safe and efficient operation.
Temperature Adjustment
Adjusting the temperature on your Devola panel heater is straightforward using the control panel. Typically, you’ll find ‘+’ and ‘-’ buttons dedicated to increasing or decreasing the desired room temperature. Each press usually adjusts the temperature in increments of one degree Celsius or Fahrenheit, depending on your model’s settings.
The current set temperature is displayed prominently on the control panel’s digital screen. Allow the heater time to reach the set temperature after adjustment. Remember that the heater will cycle on and off to maintain the desired warmth, conserving energy.
For optimal comfort, start with a moderate temperature and adjust gradually. Consider the room size and insulation when selecting a suitable temperature.
Timer Functions
Devola heaters offer versatile timer options, including automatic and manual modes, allowing users to schedule heating periods for convenience and energy efficiency.
Customize your heating schedule to match your lifestyle, optimizing comfort and reducing energy consumption.
Automatic Timer Mode
Utilizing the Automatic Timer Mode simplifies heating management by allowing the Devola panel heater to follow a pre-programmed, 24-hour schedule. This feature is ideal for maintaining a consistent temperature throughout the week with minimal user intervention. To activate, navigate to the timer settings on the control panel and select “Automatic Mode”.
The heater will then operate based on the default factory settings, or any previously saved custom schedule. This mode is particularly useful for regular heating patterns, such as warming up a room before you wake up or returning home from work. Remember to review and adjust the schedule if your routine changes to maximize energy savings and comfort. The automatic timer ensures consistent warmth without constant manual adjustments, providing a convenient and efficient heating solution.
For optimal performance, ensure the heater’s internal clock is accurately set.
Manual Timer Mode: Setting a Custom Schedule
Manual Timer Mode offers personalized heating control, allowing you to create a heating schedule tailored to your specific lifestyle. To begin, access the timer settings on the control panel and select “Manual Mode”. You’ll then be prompted to set individual on/off times for each day of the week.
This allows for precise temperature management, ensuring warmth only when and where you need it. Input the desired start and end times for each heating period, considering your daily routines. Save your settings, and the heater will adhere to your customized schedule. This mode is perfect for irregular schedules or when you require more granular control over your heating.
Remember to double-check your programmed times to avoid unnecessary energy consumption or discomfort. Enjoy the flexibility of a heating schedule designed entirely around your needs!
7-Day Timer Programming (DVM2000W Specific)
The DVM2000W model features a sophisticated 7-day timer, offering unparalleled control over your heating schedule. Access the timer function via the control panel and select “7-Day Timer”. This allows you to program unique heating profiles for each day of the week, accommodating varying schedules.
For each day, you can set multiple on/off periods with specific start and end times. This granular control optimizes energy efficiency and ensures comfort precisely when you need it. Save each day’s settings individually, creating a fully customized weekly heating plan.
The 7-day timer is ideal for households with dynamic routines. Review your programmed schedule regularly to ensure it aligns with your lifestyle. Enjoy consistent warmth and significant energy savings with this advanced feature!
Advanced Features
Devola heaters offer enhanced functionality, including frost protection, a child safety lock, and eco mode for optimized energy use and user peace of mind.
Frost Protection Mode
Protecting your space from freezing temperatures is crucial, and your Devola panel heater is equipped with a dedicated Frost Protection Mode to ensure consistent warmth during colder months. This intelligent feature automatically activates the heating element when the ambient temperature drops below a pre-set level, typically around 5°C (41°F).
Unlike standard operation, Frost Protection Mode operates at a lower power output, consuming minimal energy while preventing pipes from freezing and protecting vulnerable areas within your home. The heater will maintain this low-level heating until the temperature rises above the set threshold, then automatically deactivate.
To activate Frost Protection Mode, refer to the control panel instructions within this manual. It’s an ideal setting for unoccupied properties or rooms prone to cold drafts, offering reliable and energy-efficient protection against the damaging effects of freezing temperatures. Ensure the heater remains powered on to benefit from this feature.
Child Safety Lock Function
Prioritizing safety is paramount, especially in households with young children. Your Devola panel heater incorporates a Child Safety Lock function, designed to prevent accidental operation or adjustments to the heater’s settings. When activated, this feature disables the touch-sensitive control panel, rendering the buttons unresponsive to curious little fingers.
Activating the lock typically involves pressing and holding a designated button on the control panel for a few seconds. A visual indicator, such as a padlock symbol, will illuminate to confirm the lock is engaged. This prevents unintended changes to the temperature, timer, or other settings, ensuring a safe heating environment.
To deactivate the Child Safety Lock, simply repeat the process – press and hold the same button until the indicator light turns off. Always remember to deactivate the lock when you need to adjust the heater’s settings. This feature provides peace of mind, allowing you to enjoy warmth without worry.
Eco Mode Operation
Embrace energy efficiency with your Devola panel heater’s Eco Mode. This intelligent feature optimizes heating performance while minimizing energy consumption, contributing to lower electricity bills and a reduced carbon footprint. Eco Mode operates by subtly adjusting the heater’s output, maintaining a comfortable temperature without excessive power usage.
Activating Eco Mode is typically achieved by pressing a dedicated “Eco” button on the control panel. The heater will then automatically adjust its settings to prioritize energy savings. While in Eco Mode, the heater may cycle on and off more frequently to maintain the desired temperature efficiently.
Eco Mode is ideal for maintaining a consistent, comfortable temperature in rooms that are not constantly occupied, or during milder weather conditions. It’s a smart choice for environmentally conscious users seeking a balance between warmth and energy conservation. Enjoy cozy warmth responsibly!
Maintenance and Troubleshooting
Regular cleaning ensures optimal performance and longevity. For common issues, consult the troubleshooting guide within this manual before contacting support.
Resetting the heater may resolve minor operational glitches, restoring functionality and providing continued, reliable warmth.
Cleaning Your Devola Panel Heater
Maintaining a clean Devola panel heater is crucial for optimal performance and longevity. Before any cleaning procedure, always ensure the heater is completely switched off and unplugged from the power outlet, allowing it to cool down entirely. This prevents the risk of electric shock and potential damage to the unit.
To clean the exterior surfaces, use a soft, dry cloth to gently wipe away dust and debris. Avoid using abrasive cleaners, solvents, or scouring pads, as these can damage the finish. For stubborn marks, a slightly damp cloth with mild soapy water can be used, but ensure it is thoroughly wrung out to prevent moisture from entering the heater’s internal components.
Do not immerse the heater in water or any other liquid. Never spray liquids directly onto the unit. Pay particular attention to the control panel, ensuring it remains dry. Regularly vacuuming around the heater can also help prevent dust buildup. Following these simple cleaning steps will help keep your Devola panel heater functioning efficiently and looking its best for years to come.
Troubleshooting Common Issues
If your Devola panel heater isn’t functioning correctly, several simple checks can resolve common issues. First, ensure the heater is properly plugged into a working power outlet. Check the fuse or circuit breaker to confirm it hasn’t tripped. If the heater doesn’t turn on, verify the power button is pressed and the indicator light illuminates.
For temperature inaccuracies, recalibrate the thermostat or ensure the room isn’t affected by drafts or external heat sources. If the timer isn’t working, double-check the programmed settings and ensure the correct mode (automatic or manual) is selected. If the heater displays an error code, consult the full user manual for specific interpretations.
Should problems persist, avoid attempting self-repair. Contact a qualified electrician or Devola customer support for assistance. Never disassemble the heater, as this will void the warranty and could pose a safety hazard. Regular maintenance and these troubleshooting steps will help maintain optimal performance.
Resetting the Heater
In certain situations, resetting your Devola panel heater may be necessary to resolve operational issues or restore factory settings. Typically, a reset involves disconnecting the heater from the power supply for a minimum of five minutes. This allows the internal components to fully discharge and clear any temporary errors.
After the waiting period, reconnect the heater and power it on. You may need to re-enter your preferred temperature settings and timer programs. If the heater continues to malfunction after a simple power cycle, consult the comprehensive user manual for model-specific reset procedures. Some models may have a dedicated reset button or a specific key combination.
Remember to always prioritize safety during the reset process. Ensure the heater is unplugged and dry before handling it. Regular resets are generally not required for normal operation, but can be a useful troubleshooting step when encountering persistent problems.
Technical Specifications
Devola panel heaters are available in 1kW, 1.5kW, and 2.4kW power options, all boasting an IP24 rating for bathroom suitability and varying dimensions.
Power Consumption (1kW, 1.5kW, 2.4kW Models)
Devola panel heaters offer a range of power outputs to suit different room sizes and heating needs. The 1kW model is ideal for smaller spaces, providing efficient warmth while minimizing energy consumption. This model typically draws approximately 1000 watts of power when operating at its maximum setting.
For medium-sized rooms, the 1.5kW heater provides a balanced solution, consuming around 1500 watts. This offers a noticeable increase in heating capacity without significantly impacting electricity bills. Finally, the 2.4kW model is designed for larger areas, delivering substantial heat with a power draw of approximately 2400 watts.
It’s important to note that actual power consumption can vary based on factors like thermostat settings, room insulation, and external temperature. Utilizing features like Eco Mode and timer functions can further optimize energy usage across all models.
IP Rating (IP24)
Devola panel heaters are rated IP24, signifying a specific level of protection against solid objects and water ingress. The first digit, ‘2’, indicates protection against solid objects greater than 12.5mm, meaning fingers or similar tools cannot easily access internal components. This safeguards against accidental electrical shock or damage.
The second digit, ‘4’, denotes protection against splashing water from any direction. This makes the heater suitable for use in bathrooms, kitchens, or other areas where occasional water splashes may occur, however, direct water jets should be avoided.
Important Note: While IP24 offers splash protection, it does not imply the heater is waterproof. Always ensure the heater is installed and used in accordance with the safety guidelines outlined in this manual to maintain its protective rating and ensure safe operation.
Dimensions and Weight
Understanding the physical specifications of your Devola panel heater is crucial for proper installation and placement within your home. Dimensions and weight vary depending on the model – 1kW, 1.5kW, or 2.4kW – so please refer to the specific details below.
While exact measurements aren’t universally provided, these heaters are generally designed to be slimline for discreet wall mounting. Expect a height and width around 60cm x 40cm, with a depth of approximately 8-10cm. The 1kW model typically weighs around 6kg, the 1.5kW around 7.5kg, and the 2.4kW model approximately 9kg.
Important: Always verify the precise dimensions and weight listed on the product packaging or the accompanying documentation before commencing installation. Ensure your wall can safely support the heater’s weight.
